suspended platform hoist

This suspended platform is ideal for building facade construction, decoration, cleaning and maintenance. ZLP series suspended platform, which is developed and produced by us, is ideal for building facade construction, decoration, cleaning and maintenance. It is also widely used in elevator installing, ship building and repairing, or in other areas such as big-size tank, bridge, embankment and chimney. ZLP series versatile knock-down platform provides workers safer, easier and more efficient platform access. Functions and Usage of New Age Suspended Working ...

Basic Info Rated Load(Kg): 630,800,1000 Length of Working Platform: 6m,7.5m,7.5m Trademark: famous brand in China Transport Package: Carton Box Specification: ISO9001: 2000 Origin: Shanghai HS Code: 84289090 Product Description For the whole machine SPECIFICATION ZLP-1000 ZLP-800 ZLP-800A ZLP-630 ZLP-500 ZLP-250 Schedule Weight (Kg) 1000 800 800 630 500 250 Hoisting Speed (m/min) 8-10 8-11 8-11 9-11 9-11 8-11 Rated Power(kw) 3 2.2 1.8 1.5 1.5 1.1 Hoist LTD100 LTD80 LTD80A LTD63 LTD50 LTD40 Safety Lock LSF308 LSF308 LSF309 LSF308 LSF308 ...

Suspended Access Platforms/Work Platform Ce SCP350/23S 1. Description Aerial work platform s also called as mast climbing work platform, which is driven by motor and gear on rack, and moves up and down along the guiding mast. It is mainly composed of driving unit, chassis, mast sections, tripod deck, guardrails, tie-ins, electric control parts etc. And has the advantages such as no precast foundation, heavy lifting capacity, high working efficiency, wide working area, great security, etc. If can lift the ...

Product Description Success Rope Suspension Platform is a professional manufacture for since 1988. The sales volume ranks No. 1 in China during the 24 years of history, longest in the industry. Success has developed a complete product range for safe ascent and descent along The facade of the high building, Max 300m. It is mainly used for the curtain wall, installation and cleanning of glass and window, Brushing and painting and so on. Working principle: The lifting hoist and electric ...

Basic Info Model NO.: many kinds Erection Position: External Scaffolding Move Method: Attached Lifting Scaffolding Scaffolding Part Type: Scaffolding Planks Construction Properties: Building Scaffold Rated Load: 100-1000kg Trademark: STRONG Transport Package: Wooden Case Specification: ZLP500~1000 Origin: Shanghai HS Code: 84313900 Product Description we can make the platform according to your special requirement Product Description: Suspended working platform is an ideal equipment for facade construction, decoration, cleaning and maintenance, and is also widely used in elevator installation, shipyard, big tank, bridge, ...

Product Description Suspended working platform is an ideal equipment for facade construction, decoration, cleaning and maintenance, and is also widely used in elevator installation, shipyard, big tank, bridge, embankment and chimney. It provides safer, easier and more efficient platform access For more details please contact us. ZLP series hoist suspended platform / swing stage 1. General Introduction for Suspended platform: ZLP series Suspended Platform is a substitute of traditional scaffold , it belongs to electrical-driven climbing and decorating machinery. 2 ...

Product Description 1.Structure of Suspended Platform (1) WorkingPlatform (2) Hoist Assembly (3) Satety Lock (4) Electric Control Panel(5) Suspension Mechanism(6) Cable(7) Wire rope 2. Usage of Suspended platform (1) Facade maintenance,paiting and cleaning of high building (2) Window cleaning and installation (3) Construction inspection and maintenance of big-size tanks,chimneys ,dams, bridges (4) Maintenance , cleaning ,painting of big ship Technical Parameters Item  ZLP250   ZLP500   ZLP630  ZLP800  ZLP1000 Rated Loading  250KG 500KG  630KG  800KG  1000KG Speed ~9.5 m/min ~9.5 ...

Quick Details Type: CONSTRUCTION EQUIPMENT Place of Origin: Shanghai, China (Mainland) Brand Name: SUCCESS Model Number: ZLP630/ZLP800/ZLP1000 Material: steel , hot galvanized, aluminum color: red, blue, yellow Brake torque: 16 rated stretch of front beam: 1500mm Voltage: 220V/380V/415V Supply Ability Supply Ability: 1000 Unit/Units per Month Packaging & Delivery Packaging Details: Wooden case, cartons and pallet Port： Shanghai SUSPENDED PLATFORM IDENTIFICATION Suspended platform is a kind of aerial working equipment for loading people, by setting up suspension frame on the ...

Quick Details Place of Origin: shanghai, China (Mainland) Brand Name:SUCCESS Model Number: ZLP630 Usage: Building facade cleaning Colour: Red or other colors Certificates: ISO, GOST, CE Power Source: Electricity Drive Type: Wire rope hoisting Application: Tall Building Maintenance Lifting Speed:8-10m/min Lifting Height and Cable Length: 100m Voltage: 380V50HZ 3Phases ZLP250, ZLP500, ZLP630, ZLP800, ZLP1000 Aluminum Suspended Platform ZLP Special Shape Suspended Platform A. Introduction of ZLP Aluminum Suspended Platform ZLP series suspended platform belongs to electrical-driven climbing and decorating machinery, ...

Quick Details Place of Origin: Shanghai, China (Mainland) Brand Name: Success Model Number: ZLP HS Code: 8428909090 Name: Platform Crane Rated load: 630kg/800kg/1000kg Lifting Height: 200m Hoist Power: 1.5kw/1.8kw/2.2kw Hoist Voltage: 380V/415V/440V Cable: 200m Counterweight: 1000kg Lifting speed: 8-10 m/min Treatment: Hot galvanized Supply Ability Supply Ability: 5000 Set/Sets per Year Platform Crane Packaging & Delivery Packaging Details Platform Crane: 1-4sets/ one set for one wooden case-5cbm/set by LCL more than 5sets / packed on pallets by FCL 20'container for ...

Product Description zlp series suspended platform is a new decorating machinery,which can repalce the traditional scaffold and have been used in many aspects,for example,exterior wall consruction,decoration, glass cleaning,ship building,bridge constrcution,chimney maintenance and repairing so on.Bacause the technology is mature,using balance suspeended platform can reduce work intensity and raise work efficiency, and it is easy to operate,so more and more people accept. The lentgh of the working platform is 5meters,which is made of two 2.5-mater platforms,the material is steel,and the surface ...

Quick Details Condition: New Place of Origin: Shanghai, China (Mainland) Brand Name: SUCCESS Usage: Construction Hoist Power Source: Electric Sling Type: Wire Rope Maximum Lifting Weight: 20t Maximum Lifting Height: 30m Lift Speed: 8m or 7m/min Certification: ISO;CE;SGS;BV Warranty: 12 month from the date of B/L After-sales Service Provided: Engineers available to service machinery overseas Crane feature: Hoist Feature: low-headroom;space saved hoist Max.lifting capacity: 20t lifting speed: 8m/min traversing speed: 20m/min Variable or dual speed: Accepted Protection class: IP54 or ...

Quick Details Condition:New Place of Origin: Shanghai, China (Mainland) Brand Name: ELK Model Number: 150410-1038 Usage: lifting equipment Power Source: Electric Sling Type: Chain Maximum Lifting Weight: 3.75ton Maximum Lifting Height: 1-100M, as customer required Lift Speed: 4.4m/min Certification: CE & ISO9001:2008 Warranty: 2 years After-sales Service Provided: No overseas service provided Hoist color: genneral yellow/Provide your required color atla Hoist chain dia.: 10.0mm Hoist chain: Japanese FEC80 or Chinese G80 Hoist chain fall: 2 Hoist shell: light aluminum alloy ...

10 Meters Aluminum Alloy Suspended Working Platform With Hoist LTD8.0 Descriptions: Application of suspended platform: 1. Highrise building: Decoration,construction for external wall,installation of curtain wall and external components, repairing, checking,maintenance and cleaning for external wall; 2. Large-scale project: construction,repairing and maintenance for large tank, chimney, dams, bridges,derrick. 3. Large ships: welding, cleaning and painting. 4. billboard: installation billboard for high-rise building. Technical Parameters Model No. ZLP800 Rated load(kg) 800 Lifting speed(m/min) 8～10 Motor power(kw) 2×1.8 50HZ/60HZ Brake torque(Km) 16 Steel ...

Detailed Product Description Steel / Hot Galvanized / Aluminium Alloy Suspended Working Platform ZLP800 with hoist LTD8.0 Quick Detail: 1. Model No.: ZLP800 2. Brand Name: HAOKE 3. Material: Steel / Aluminum 4. Appearance: Plastic Spray Painted / Hot Galvanized 5. Capacity Loading: 800 KG 6. Lifting Height: Maximum 300 Mts Applications: 1. Cleaning and maintaining of the exterior wall of high-rise building. 2. Painting, decoration and refurbishing of exterior walls. 3. Installation projects and other construction working of outer ...

Property Model No. ZLP630 Rated load(kg) 630 Lifting speed(m/min) 9～11 Motor power(kw) 2×1.5 50HZ/60HZ Brake torque(Km) 16 Steel rope angle adjusting range(°) 3°- 8° Distance between two steel rope(mm) ≤100 Rated stretch of front beam(mm) 1500 Suspending platform Locking Aluminum alloy Nr.Of platform rack Single rack Nr.Of platform 3 L×W×H(mm) (2000×3)×690×1180 Weight(kg) 375 Kg Suspending mechanism(kg) 2×175 Kg Counterweight(kg) optional 25×36pcs Diameter of steel rope(mm) 8.3 Max Lifting height(m) 300 Motor rotation speed(r/min) 1420 Voltage(v) 3PHASES/Single Phase 220V/380V/415V (customized) Detailed ...

Property Model No. ZLP800 Rated load(kg) 800 Lifting speed(m/min) 8～10 Motor power(kw) 2×1.8 50HZ/60HZ Brake torque(Km) 16 Steel rope angle adjusting range(°) 3°- 8° Distance between two steel rope(mm) ≤100 Rated stretch of front beam(mm) 1500 Suspending platform Locking Aluminum alloy Nr.Of platform rack Single rack Nr.Of platform 3 L×W×H(mm) (2500×3)×690×1180 Weight(kg) 410 Kg Suspending mechanism(kg) 2×175 Kg Counterweight(kg) optional 25×40pcs Diameter of steel rope(mm) 8.6 Max Lifting height(m) 300 Motor rotation speed(r/min) 1420 Voltage(v) 3PHASES 220V/380V/ 415V Competitive advantages: ...

Property Model No. ZLP630 Rated load(kg) 630 Lifting speed(m/min) 9～11 Motor power(kw) 2×1.5 50HZ/60HZ Brake torque(Km) 16 Steel rope angle adjusting range(°) 3°- 8° Distance between two steel rope(mm) ≤100 Rated stretch of front beam(mm) 1500 Suspending platform Locking Aluminum alloy Nr.Of platform rack Single rack Nr.Of platform 3 L×W×H(mm) (2000×3)×690×1180 Weight(kg) 375 Kg Suspending mechanism(kg) 2×175 Kg Counterweight(kg) optional 25×36pcs Diameter of steel rope(mm) 8.3 Max Lifting height(m) 300 Motor rotation speed(r/min) 1420 Voltage(v) 3PHASES 220V/380V/415V (customized) Competitive advantages: ...

Specifications: Property Model No. ZLP630 Rated load(kg) 630 Lifting speed(m/min) 9～11 Motor power(kw) 2×1.5 50HZ/60HZ Brake torque(Km) 16 Steel rope angle adjusting range(°) 3°- 8° Distance between two steel rope(mm) ≤100 Rated stretch of front beam(mm) 1500 Suspending platform Locking Aluminum alloy Nr.Of platform rack Single rack Nr.Of platform 3 L×W×H(mm) (2000×3)×690×1180 Weight(kg) 375 Kg Suspending mechanism(kg) 2×175 Kg Counterweight(kg) optional 25×36pcs Diameter of steel rope(mm) 8.3 Max Lifting height(m) 300 Motor rotation speed(r/min) 1420 Voltage(v) 3PHASES 220V/380V/415V (customized) Competitive ...

L strirrup Aluminum 250kg Single Man Suspended Platform There are 3 kinds available for each model of Europa brand Suspended platform. They’re steel painted,hot galvanized,aluminum alloy. Property Model No. ZLP250 ZLP500 ZLP630 ZLP800 ZLP1000 Rated load(kg) 250 500 630 800 1000 Lifting speed(m/min) 9～11 9～11 9～11 8～10 8~10 Motor power(kw) 1×1.5 50HZ/60HZ 2×1.5 50HZ/60HZ 2×1.5 50HZ/60HZ 2×1.8 50HZ/60HZ 2×2.2 50HZ/60HZ Brake torque(Km) 16 16 16 16 16 Steel rope angle adjusting range(°) 3°- 8° 3°- 8° 3°- 8° 3°- 8° ...
